Jan De Nul orders innovative Motion-Compensated Pile Gripper for its Floating Installation Vessel Les Alizés


  • Jan De Nul awards Imeca the design and manufacture of a highly advanced electrical Motion-Compensated Pile Gripper for its Floating Installation Vessel, Les Alizés.
  • Jan De Nul continues to invest in new mission equipment to find solutions for next generation offshore wind installation challenges.
  • The innovative Imeca pile gripper, including X-Laboratory Technology, increases operational control thanks to an integrated survey system and high-levels of redundancy throughout.

Jan De Nul Group has selected Imeca, a trade mark of REEL SAS, for the delivery of a highly advanced electrical Motion-Compensated Pile Gripper for its new Floating Installation Vessel Les Alizés. The tailor-made gripper, with an integrated X-Laboratory guidance and survey system, will allow safe and efficient installation of next-generation monopiles with pin-point accuracy. Gripper delivery is planned for H2 2022 and this new mission equipment helps to future proof Jan De Nul Group foundation installation capability.

With the construction of both Les Alizés and the Jack-Up Installation Vessel Voltaire well underway, Jan De Nul Group will shortly have the capability to not only install next-generation foundations, but also wind turbines (WTGs), safely and efficiently.

Jan Van De Velde, Head of Newbuilding Department: “It is our continued philosophy to focus on operational efficiency, with improving safety as the main objective. For this innovative Motion-Compensated Pile Gripper we have challenged our suppliers to meet our functional requirements. Imeca is an experienced system integrator with a solid offshore track record, and will form a strong team with its complimentary partner X-Laboratory, known for its innovative plug-and-play control solutions for offshore wind applications. With this gripper investment, we stay one step ahead in offering the renewables industry a one-stop-shop installation solution.”

Improved safety and operational control

Les Alizés allows the installation of very large components including jackets exceeding 4,500 mt, and heights in excess of 100 m; and monopiles weighing over 3,000 mt and an outer diameter exceeding 12 m.  It is of paramount importance that the installation process for these very large components can be safely executed.

Jan Van De Velde:Previously tools and mission equipment were designed to fit for one project. Now our tools are designed to cover the requirements of current and future projects. This approach considerably increases sustainability as tools can be used for multiple projects, and safety risk reduces as the operators become familiar with the equipment.”

The Imeca Motion-Compensated Pile Gripper will have some very unique features that will increase operational control during the installation process, including:

An integrated survey system that enables continuous monitoring of the monopile from insertion into the gripper to hammering completion. This will considerably improve the control over the monopile and will positively affect the decision-making process between operational steps.

Thanks to the X-Laboratory Guidance System’s embedded emergency recovery control mode, the gripper will be able to control the monopile even in the hypothetical absence of the DP system and thrusters. The gripper will operate autonomously to keep the monopile and vessel stable, long enough to return all systems to a safe state.

Kara Konate, Technical Director Imeca:We are at our best as sparring partner for our clients, deeply involved in their operational process where our solutions can make a difference. The challenge for this gripper project was to have a safe and reliable solution providing the required workability in all operational phases in an efficient manner. This requires a tremendous precision and reactivity on a large machine. We have achieved this through an innovative low friction bearing system and our internally developed electric drive and control system making use of permanent magnet assisted electric motors. Supercaps are used to reduce the power demand from the vessel. We are very proud to have been selected and look forward to our cooperation with Jan De Nul and our partners.”

 André Schiele, CEO X-Laboratory:Handling large monopiles safely and with high accuracy during the various installation phases of a floating operation is a profound engineering challenge. We applied our Space Engineering heritage to the development of the X-Control Guidance System and the X-Cam Survey Sensor Suite, which we initially developed for our PuppeteerTM motion compensation tool. Jan De Nul’s monopile gripper will be equipped with the latest state-of-the-art technology and fulfil strict redundancy requirements. It will allow resource efficient, weather robust and high-reliability operations, delivering the potential to disrupt the floating wind pile installation market. We are proud to be contributing our products and technology to this exciting development of Imeca and Jan De Nul.

About Jan De Nul Group
Design. Build. Connect. Jan De Nul Group shapes water and land. Worldwide. From complex services to the offshore energy and energy transition sector, over large dredging and defence works on the edge of water and land, to challenging civil and environmental works. Well integrated competences and investments lead to creative, sustainable and innovative solutions. In this way Jan De Nul Group delivers results that produce satisfied customers. Not only today, but also tomorrow. –
www.jandenul.com



About Imeca, a trade mark of REEL SAS

At Imeca we enable our clients to construct the infrastructure  for offshore energy production and offshore transshipment. We are at our best as sparring partner for our clients, deeply involved in their operational process where our solutions can make a difference. We are client driven with a strong technological base, Rational, Economic, Elegant & Light is part of our DNA.  This way Imeca provides large-scale lifting, handling  and integrated systems & services fully compliant to its clients expectations and beyound.

Imeca is a trade mark of REEL SAS – www.imeca-reel.com



About X-Laboratory
X-Laboratory is a Rotterdam based high-tech research and development firm composed of highly skilled space engineering, automation and control experts. X-Laboratory conceives highest state of the art active motion compensation systems for the offshore wind industry, aimed at enabling floating-to-fixed and floating-to-floating construction of offshore wind parks. –
www.deltaxlab.com
